Colors conform to OSHA 1910.144 for marking requirements:
BLACK/YELLOW: Physical Hazards
BLACK/WHITE: Housekeeping and Aisle Marking
RED/WHITE: Fire Protection Equipment
BLUE/WHITE: Defective Equipment Warning
ORANGE/WHITE: Traffic and Caution Warning
GREEN/WHITE: Safety and First Aid
MAGENTA/YELLOW: Radiation Hazards
Technical Specifications
Laminated tapes: HAZARD WARNING TAPE
APPLICATION:
Designed expressly for safety marking applications in industrial plants,
commercial buildings, institutions and recreational facilities.
Tape fulfills all OSHA requirements. Used to mark obstructions, low hanging
objects, pillars, handrails, passageways, aisles and any potentially
hazardous
areas or objects.
FEATURES / BENEFITS:
Engineered to hold up under the heaviest most abusive traffic and wear
longer than paint!
Clear embossed protective PVC laminated to a printed PVC layer to give a
total backing thickness of 5 mils.
Prevents fading and scuffing; provides
super abrasion resistance.
Can be applied quickly and easily; requires minor surface preparation, with no
time consuming scraping and cleaning necessary.
No downtime required for drying after installation.
Maintenance-free. Original color brilliance is continually renewed
by simple wet mopping/washing.
Conforms with OSHA requirements.
TECHNICAL DATA:
Backing Material: Polyvinylchloride (PVC) film
Adhesive: Rubber Based
Total Tape Thickness: 6.0 mils / 0.150 mm
Tensile Strength: 18 lbs. per in. / 3.22 kg per cm
Unwind @ 150 FPM: 65 oz. per in. / 725 gm per cm
Adhesion to steel: 30 oz. per in. / 335 gm per cm
OSHA requirements: Per paragraph 1910.144 of the Federal
Register
Note: The above are typical values and should not be used in writing specifications.
